P 系列 | 內徑 I.D. | 線徑W |
---|---|---|
P2 | 1.8 | 1.9 |
P3 | 2.8 | 1.9 |
P4 | 3.8 | 1.9 |
P5 | 4.8 | 1.9 |
P6 | 5.8 | 1.9 |
P7 | 6.8 | 1.9 |
P8 | 7.8 | 1.9 |
P9 | 8.8 | 1.9 |
P10 | 9.8 | 1.9 |
P10A | 9.8 | 2.4 |
P11 | 10.8 | 2.4 |
P11.2 | 11 | 2.4 |
P12 | 11.8 | 2.4 |
P12.5 | 12.3 | 2.4 |
P14 | 13.8 | 2.4 |
P15 | 14.8 | 2.4 |
P16 | 15.8 | 2.4 |
P18 | 17.8 | 2.4 |
P20 | 19.8 | 2.4 |
P21 | 20.8 | 2.4 |
P22 | 21.8 | 2.4 |
P22A | 21.7 | 3.5 |
P22.4 | 22.1 | 3.5 |
P24 | 23.7 | 3.5 |
P25 | 24.7 | 3.5 |
P25.5 | 25.2 | 3.5 |
P26 | 25.7 | 3.5 |
P28 | 27.7 | 3.5 |
P29 | 28.7 | 3.5 |
P29.5 | 29.2 | 3.5 |
P30 | 29.7 | 3.5 |
P31 | 30.7 | 3.5 |
P31.5 | 31.2 | 3.5 |
P32 | 31.7 | 3.5 |
P34 | 33.7 | 3.5 |
P35 | 34.7 | 3.5 |
P35.5 | 35.2 | 3.5 |
P36 | 35.7 | 3.5 |
P38 | 37.7 | 3.5 |
P39 | 38.7 | 3.5 |
P40 | 39.7 | 3.5 |
P41 | 40.7 | 3.5 |
P42 | 41.7 | 3.5 |
P44 | 43.7 | 3.5 |
P45 | 44.7 | 3.5 |
P46 | 45.7 | 3.5 |
P48 | 47.7 | 3.5 |
P49 | 48.7 | 3.5 |
P50 | 49.7 | 3.5 |
P48A | 47.6 | 5.7 |
P50A | 49.6 | 5.7 |
P系列 | 內徑 I.D. | 線徑W |
---|---|---|
P52 | 51.6 | 5.7 |
P53 | 52.6 | 5.7 |
P55 | 54.6 | 5.7 |
P56 | 55.6 | 5.7 |
P58 | 57.6 | 5.7 |
P60 | 59.6 | 5.7 |
P62 | 61.6 | 5.7 |
P63 | 62.6 | 5.7 |
P65 | 64.6 | 5.7 |
P67 | 66.6 | 5.7 |
P70 | 69.6 | 5.7 |
P71 | 70.6 | 5.7 |
P75 | 74.6 | 5.7 |
P80 | 79.6 | 5.7 |
P85 | 84.6 | 5.7 |
P90 | 89.6 | 5.7 |
P95 | 94.6 | 5.7 |
P100 | 99.6 | 5.7 |
P102 | 101.6 | 5.7 |
P105 | 104.6 | 5.7 |
P110 | 109.6 | 5.7 |
P112 | 111.6 | 5.7 |
P115 | 114.6 | 5.7 |
P120 | 119.6 | 5.7 |
P125 | 124.6 | 5.7 |
P130 | 129.6 | 5.7 |
P132 | 131.6 | 5.7 |
P135 | 134.6 | 5.7 |
P140 | 139.6 | 5.7 |
P145 | 144.6 | 5.7 |
P150 | 149.6 | 5.7 |
P150A | 149.5 | 8.4 |
P155 | 154.5 | 8.4 |
P160 | 159.5 | 8.4 |
P165 | 164.5 | 8.4 |
P170 | 169.5 | 8.4 |
P175 | 174.5 | 8.4 |
P180 | 179.5 | 8.4 |
P185 | 184.5 | 8.4 |
P190 | 189.5 | 8.4 |
P195 | 194.5 | 8.4 |
P200 | 199.5 | 8.4 |
P205 | 204.5 | 8.4 |
P209 | 208.5 | 8.4 |
P210 | 209.5 | 8.4 |
P215 | 214.5 | 8.4 |
P220 | 219.5 | 8.4 |
P225 | 224.5 | 8.4 |
P230 | 229.5 | 8.4 |
P235 | 234.5 | 8.4 |
P240 | 239.5 | 8.4 |
P系列 | 內徑 I.D. | 線徑W |
---|---|---|
P245 | 244.5 | 8.4 |
P250 | 249.5 | 8.4 |
P255 | 254.5 | 8.4 |
P260 | 259.5 | 8.4 |
P265 | 264.5 | 8.4 |
P270 | 269.5 | 8.4 |
P275 | 274.5 | 8.4 |
P280 | 279.5 | 8.4 |
P285 | 284.5 | 8.4 |
P290 | 289.5 | 8.4 |
P295 | 294.5 | 8.4 |
P300 | 299.5 | 8.4 |
P305 | 304.5 | 8.4 |
P310 | 309.5 | 8.4 |
P315 | 314.5 | 8.4 |
P320 | 319.5 | 8.4 |
P325 | 324.5 | 8.4 |
P330 | 329.5 | 8.4 |
P335 | 334.5 | 8.4 |
P340 | 339.5 | 8.4 |
P345 | 344.5 | 8.4 |
P350 | 349.5 | 8.4 |
P355 | 354.5 | 8.4 |
P360 | 359.5 | 8.4 |
P365 | 364.5 | 8.4 |
P370 | 369.5 | 8.4 |
P375 | 374.5 | 8.4 |
P380 | 379.5 | 8.4 |
P385 | 384.5 | 8.4 |
P390 | 389.5 | 8.4 |
P395 | 394.5 | 8.4 |
P400 | 399.5 | 8.4 |
P405 | 404.5 | 8.4 |
P410 | 409.5 | 8.4 |
P415 | 414.5 | 8.4 |
P420 | 419.5 | 8.4 |
P425 | 424.5 | 8.4 |
P430 | 429.5 | 8.4 |
P435 | 434.5 | 8.4 |
P440 | 439.5 | 8.4 |
P445 | 444.5 | 8.4 |
P450 | 449.5 | 8.4 |
P455 | 454.5 | 8.4 |
P460 | 459.5 | 8.4 |
P465 | 464.5 | 8.4 |
P470 | 469.5 | 8.4 |
P475 | 474.5 | 8.4 |
P480 | 479.5 | 8.4 |
P485 | 484.5 | 8.4 |
P490 | 489.5 | 8.4 |
P495 | 494.5 | 8.4 |
P系列 | 內徑 I.D. | 線徑W |
---|---|---|
P500 | 499.5 | 8.4 |
P505 | 504.5 | 8.4 |
P510 | 509.5 | 8.4 |
P515 | 514.5 | 8.4 |
P520 | 519.5 | 8.4 |
P525 | 524.5 | 8.4 |
P530 | 529.5 | 8.4 |
P535 | 534.5 | 8.4 |
P540 | 539.5 | 8.4 |
P545 | 544.5 | 8.4 |
P550 | 549.5 | 8.4 |
P555 | 554.5 | 8.4 |
P560 | 559.5 | 8.4 |
P565 | 564.5 | 8.4 |
P570 | 569.5 | 8.4 |
P575 | 574.5 | 8.4 |
P580 | 579.5 | 8.4 |
P585 | 584.5 | 8.4 |
P590 | 589.5 | 8.4 |
P595 | 594.5 | 8.4 |
P600 | 599.5 | 8.4 |
P610 | 609.5 | 8.4 |
P620 | 619.5 | 8.4 |
P630 | 629.5 | 8.4 |
P640 | 639.5 | 8.4 |
P650 | 649.5 | 8.4 |
P660 | 659.5 | 8.4 |
P670 | 669.5 | 8.4 |
P680 | 679.5 | 8.4 |
P690 | 689.5 | 8.4 |
P700 | 699.5 | 8.4 |
P710 | 709.5 | 8.4 |
P720 | 719.5 | 8.4 |
P730 | 729.5 | 8.4 |
P740 | 739.5 | 8.4 |
P750 | 749.5 | 8.4 |
P760 | 759.5 | 8.4 |
P770 | 769.5 | 8.4 |
P780 | 779.5 | 8.4 |
P790 | 789.5 | 8.4 |
P800 | 799.5 | 8.4 |
P810 | 809.5 | 8.4 |
P820 | 819.5 | 8.4 |
P830 | 829.5 | 8.4 |
P840 | 839.5 | 8.4 |
P850 | 849.5 | 8.4 |
P860 | 859.5 | 8.4 |
P870 | 869.5 | 8.4 |
P880 | 879.5 | 8.4 |
P890 | 889.5 | 8.4 |
P900 | 899.5 | 8.4 |
